DIP Type LT10.7M 10.7 MHz FM Ceramic Filter 10.7MHz

FOB Reference Price:Get Latest Price
US $0.08-0.12 / Pieces | 10 Piece/Pieces 10 Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
WTL
Model Number:
WTL2.01044ZX
Type:
Ceramic Filter
Transfer Function:
Band Pass
Package Type:
Throught Hole
Nominal Center Frequency:
10.7MHz
3dB Bandwidth:
280±50 KHz
Insertion Loss:
6.0dB Max
Input Impedance:
330Ω
Stopband Attenuation:
30dB
Ripple:
1.0 dB MAX
Operating Temperature Range:
-40+85C
Samples:
Accept
OEM/ODM:
Welcome
Warranty:
Global 180 Days Return
About Us:
17 Years Experience
Certificate:
ISO9001, ISO14000, SGS, RoHS
Shipment:
DHL, UPS, TNT, Fedex, EMS,China Post
Factory Manufacturer:
Yes
Item:
Ceramic Filter 10.7MHz
Supply Ability
Supply Ability:
10000000 Piece/Pieces per Month Ceramic Filter 10.7MHz
Packaging & Delivery
Packaging Details
Boxes and Carton, 500pcs/Box(DIP Type LT10.7M 10.7 MHz FM Ceramic Filter 10.7MHz)
Port
Shenzhen port
Lead Time :
20 workdays

DIP Type LT10.7M 10.7 MHz FM Ceramic Filter 10.7MHz

Ceramic Filter 10.7MHz

WTL----Win-win To Long

WTL is a professional manufacturer of Quartz Crystal Electronic Components in China, Established in 2001, Which Specializes in researching & developing, producing and marketing, WTL offers kinds of crystals in order to pace with wide applications.whatever you do need ,standard or high-class requirement on special fields, we will support you right quartz crystal resonator and oscillator with 100% repliability insurance.

Website: www.wtlcrystals.com



1.RATING

Items

Requirement

Withstand DC Voltage

50V (1min max)

Insulation Resistance  MΩ min.

100(10V,1min±5s)

Operating temperature

-40℃~85℃

Storage temperature

-40℃~85℃



2.Electrical Specifications

Item

Requirements

Center Frequency  fo (MHz)

10.700±0.030

3dB Band Width  (kHz)

150±40

20dB Band Width  (kHz) max

360

Insertion Loss  (dB)

4.5±2.0

Ripple (within 3dB bandwidth) (dB) max

1.0

Spurious Response  (dB) min

35  (9—12MHz)

Input/Output Impedance  (Ω)

330



DIP Type LT10.7M 10.7 MHz FM Ceramic Filter 10.7MHz

Ceramic Filter 10.7MHzCeramic Filter 10.7MHz

Packaging & Shipping



Ceramic Filter 10.7MHz

Our Services



Ceramic Filter 10.7MHz

1.17 Years Experience

2.PCB VS Crystal Matching Test for Free

3.FAE Support

4.Certification: ISO9001, ISO14001, SGS, RoHS

5.Provide A Full Set of Reliability Lab

6.Door to Door Service

7.Global 180 Days Return

8.Over 72 Countries and Regions, 27 Distributors

9.Custom-made Frequencies Due to we have our own Wafer Production Line



Our factory has a history of 17 years and it is located on West wing, Cui Hu 3rd road, Tongling City, Anhui Province, China. It covers an area of 6000 square meters. It has over 200 workers, Include Production, QA, QC, Warehouse, R&D, Technical, IQC. Welcome to Our Factory!



WTL Factory Video:https://www.youtube.com/watch?v=-orK7PXNjU8

Ceramic Filter 10.7MHz

FAQ



1.What is the general lead-time of the products?

ProductLead Time
HC49 Series1-2 weeks
SMD Crystal1-4 weeks
DIP Oscillator1-2 weeks
SMD Oscillator1-3 weeks
TCXO2-8 weeks
Watch Crystal1-2 weeks

2.Since the lead-time is set, what about samples?

Usually the samples are needed the same lead time. By the way, we can offer each customer 10-20PCS samples free of charge.



3.What basic information to provide when ordering a crystal?

Generally we request the customer to provide the center frequency, type of cutting angle(AT/BT), holder or package type, resistance(ESR), frequency tolerance, frequency stability, load capacitance, operating temperature, drive power, aging, etc, Customer can also specify other specific spec or requirement, if any, when placing orders.



4.What is the WTL main material?

TypeVendor
Crystal Bar

South Urals,Russia- Crystal Factory, TF

Base

SMI/NTK/KYOCERA(JP)

IC

NPC- Japan

Top Cover

Hua Nu Dike/Yoshikawa Corporation (JP)

Conductive Glue

Three Bond – (JP)
