10% OFF! WTL SMD 1575R-A Passive 25-25-4mm Ceramic GPS Antenna

FOB Reference Price:Get Latest Price
US $0.69-0.99 / Pieces | 10 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
WTL
Model Number:
WTL2.07976ZX
Nominal frequency:
1575.42±1.023 MHz
Center frequency:
1580±3.0 MHz
Dimension:
25*25*4mm
Application:
GPS
Polarization Model:
RHCP
Working Temperature:
-40℃ to +85℃
Warranty:
Global 180 Days Return
About Us:
18 Years Experience
Payment:
T/T, Western Union, PayPal,Credit Card
Shipment:
DHL, UPS, TNT, Fedex, EMS,China Post
Supply Ability
Supply Ability:
1000000 Piece/Pieces per Month 1575R-A Passive 25-25-4mm Ceramic GPS Antenna
Packaging & Delivery
Packaging Details
Pack in tray,1K/Carton.(10% OFF! WTL SMD 1575R-A Passive 25-25-4mm Ceramic GPS Antenna)
Port
Shenzhen
Lead Time :
Quantity(Pieces) 1 - 50000 >50000
Est. Time(day) 30 To be negotiated

10% OFF! WTL SMD 1575R-A Passive 25-25-4mm Ceramic GPS Antenna

WTL----Win-win To Long

WTL is a professional manufacturer of Quartz Crystal Electronic Components in China, Established in 2001, Which Specializes in researching & developing, producing and marketing, WTL offers kinds of crystals in order to pace with wide applications.whatever you do need ,standard or high-class requirement on special fields, we will support you right quartz crystal resonator and oscillator with 100% repliability insurance.

Website: www.wtlcrystals.com



FEATURE

1.Various Applications: GPS+GLONASS,GPS+COMPASS and Multimode;

2. Various sizes:  9X9mm to 78 x 78mm;

3.Matching Study for special application is  available

4.Dielectric antenna for RFID tag UHF RFID

5.Tag that can be tailor-made



ELECTRICAL SPECIFICATIONS

WTL SMD 1575R-A Passive 25-25-4mm Ceramic GPS Antenna

Item

Specifications

P/N

WTL2.07976ZX

Nominal frequency  MHz

1575.42±1.023

Center frequency  MHz

(without tape on 70×70mm ground plane)

1580±3.0

-10dB Bandwidth  MHz min

9.0

VSWR at CF max

2.0

Gain(peak)

5dBi min

Polarization Model

RHCP

Permittivity

21

Impedance

50 Ω

Frequency Temperature Coefficient

20ppm/deg.℃ max -40 ~ +105℃



Working and Storage CONDITION

Working Temperature

-40℃ to +85℃

Storage Temperature

-40℃ to +105℃

Storage Humidity

10% to 80% RH



10% OFF! WTL SMD 1575R-A Passive 25-25-4mm Ceramic GPS Antenna



Application



1.18 Years Experience

2.FAE Support

3.Certification: ISO9001, ISO14001, SGS, RoHS

4.Provide A Full Set of Reliability Lab

5.Door to Door Service

6.Global 180 Days Return

7.Over 72 Countries and Regions, 27 Distributors





FAQ



1.What is the general lead-time of the products?

 It takes around 4 weeks, but it depends on your quantity, pls let me know your qty. then we will arrange the best delivery time for you.



2.Your price is too high, can you offer lower price?

As you know, we import all material from the best place, and we have strict quality control process, we are not like stock seller in the market, all our products are produced with fresh date, as a big customer like you, I think the most important point for your is QUALITY, from the relationship we are having, you have chosen us as your long-term partner, so I am sure you are satisfied with our quality and service. I agree that you can find cheaper products, but you will not be happy with its stability. We have been in the industry for 18 years now, trust me we won’t offer you higher price.



3.We need the part urgently, can you deliver it within 1 week? 4 weeks is too long for us.

According to normal process for this part, it really need such time for production, we have to make sure every part is strictly controlled under the requirements, if we push the workers to make it in a hurry, I cannot promise you the products quality. We have arrange best delivery time for you, pls be patient with the process.



4.How can I pay pls?

We accept L/C, TT, Paypal and West Union. But I recommend you to make payment from Alibaba, it is very easy and convenient, let me guide you for the process.
